Ứng dụng thực tiễn PLC máy bôi kem thiếc - 8

Địa chỉ

Tên

Kiểu dữ liệu

1

D0001.1

READY SW

BIT

2

D0001.2

START SW

BIT

3

D0001.3

AUTO/MANUAL SW

BIT

4

D0001.4

STOP SW

BIT

5

D0001.5

JOG HIGH SPEED SW

BIT

6

D0001.7

CONVEYOR SW

BIT

7

D0001.8

STOPER1 SW

BIT

8

D0001.9

STOPER2 SW

BIT

9

D0001.A

LOCATE SW

BIT

10

D0001.B

UP/DW CYL SW

BIT

11

D0001.C

DISPENSOR SW

BIT

12

D0001.D

CLEAN SW

BIT

13

D0001.E

Z AXIS CYL SW

BIT

14

D0001.F

NO NEEDLE

BIT

15

D0002.0

JOG+ SW

BIT

16

D0002.1

JOG- SW

BIT

17

D0002.2

ORG SW

BIT

18

D0002.3

MOVE P0 SW

BIT

19

D0002.4

MOVE P1 SW

BIT

20

D0002.6

TABLE CYL SW

BIT

21

D0002.A

TEST BOND SW

BIT

22

D0500

DATA POS P1

WORD

23

D0506

DATA POS P0

WORD

24

D0510

AUTO SERVO SPEED

WORD

25

D0600

DATA DISPENSOR TIME 1ST

WORD

26

D0602

CLEAN TIME

WORD

27

D0604

COUNTER CLEAN

WORD

D0700

DATA DISPENSOR TIME 2ND

WORD

29

M0200

ALL READY

BIT

30

M0201

AUTO RUN

BIT

31

M0210

ORG LAMP

BIT

32

M0211

P0 POSITION

BIT

33

M0212

P1 LAMP

BIT

34

M0520

CONVEYOR LAMP

BIT

35

M0521

STOPER1 LAMP

BIT

36

M0522

STOPER2 LAMP

BIT

37

M0523

LOCATE LAMP

BIT

38

M0524

UP/DW 1 LAMP

BIT

39

M0525

DISPENSOR LAMP

BIT

40

M0526

CLEAN LAMP

BIT

41

M0527

UP/DW 2 LAMP

BIT

42

M0528

MOVE P0 LAMP

BIT

43

M0529

MOVE P1 LAMP

BIT

44

M2000

JOG HIGH SPEED

BIT
