(Pao li, 1908); M. minusminus (Paoli, 1908); O. nova (Oudemans, 1902); T. minor
Berlese, 1903.
+ There were 6 species distributed at two survey times (accounting for 14.63% of the total number of species in the day-night cycle): E. crassisetiger Aoki, 1959; S. ruzsinszkyi Mahunka, 1983; S. minima Hammer, 1979; S. ornata (Hammer, 1979); S. africanus (Wallwork, 1964);
P. kaszabi Mahunka, 1988.
There are 13 species distributed only at one survey time (accounting for 31.70% of the total number of species in the day-night cycle), specifically:
+ At 12:00, there were 5 species: C. lata Aoki, 1961; U. clavatus Aoki, 1967; N. crisposetosa (Hammer, 1979); A. cocuyana (Balogh, 1984) and Q. quadricarinata (Michael, 1885).
+ At 18:00 there were 4 species: C. lanatus (Michael, 1885); M. brevipectinata Suzuki, 1976; S. sabahensis Mahunka, 1988; S. magnifera (Mahunka, 1978).
+ At 24:00 there are 4 species, specifically: S. quinquenodosa Balogh, 1968;
Perxylobates sp.; P. margaritata Mahunka, 1989, M. calcarata (Mahunka, 1978).
Thus, the data shows that the species are distributed quite widely between the time points. In particular, it is observed that a large number of taxa are concentrated at all four time points: 6:00 - 12:00 - 18:00 - 24:00, similar to a certain time point. In the four survey times, the time point 6:00 has the lowest number of recorded species-level taxa, the number of taxa increases and reaches the highest at 12:00 and 18:00.
3.4.2. Biodiversity in the day-night cycle
From the data in table 3.14 and figure 3.19, it can be seen that:
Between the time points, the number of species fluctuated from 14 to 25, the highest at 16:00 and 18:00 with 25 species (accounting for 60.97% of the total number of species), at 24:00 it decreased to 20 species (accounting for 48.78% of the total number of species), the lowest decrease at 6:00 with only 14 species (accounting for 34.14% of the total number of species). The difference in the number of species recorded between the time points was statistically significant with (P<0.05).
So in general, in the four survey times, the number of species is usually highest in the period from 12:00 to 18:00 and lower in the other two times. This fluctuation seems to be associated with the fluctuation of the day-night cycle with the most obvious changes in temperature, light, etc.
Number of species
30
Individual MDT/m 2
30000
25
25000
20
17240
20
20000
0
15
15000
10
MDT
S
6760
10000
5
5000
0
6:00
12:00
18:00
24h00
0
Day and night cycle
25
25
2
416
14
4560
Figure 3.19. Number of species and average density of oribatid mite communities during the day-night cycle
The average density (MDTB, individuals/m 2 ) of the four time points ranged from 4560 (individuals/m 2 ) - 24160 (individuals/m 2 ). The average density tended to decrease gradually from 12:00 (24160 individuals/m 2 ) > 18:00 (17240 individuals/m 2 ) > 24:00 (6760 individuals/m 2 ) > 6:00 (4560 individuals/m 2 ). Thus, it can be seen that the number of species and MDTB of individuals have similar fluctuations.
with the number and density usually peaking between 1200 and 1800, and the lowest at 6000 in the morning.
From the data in table 3.14 and figure 3.20 it can be seen that:
Species richness (d) of the oribatid mite community reached its highest at 18:00 with an average of 3.02 ± 0.29, the highest was 3.33 and the lowest was 2.76. Next was 12:00 with 2.76 ± 0.91, the highest was 3.48 and the lowest was 1.74. At 24:00 it reached 2.6 ± 1.04, the highest was 3.45 and the lowest was 1.44. Species richness was lowest at 6:00 with 2.1 ± 0.42, the highest was 2.53 and the lowest was 1.7. The average species richness index (d) at different times was statistically significant (P<0.05).
Table 3.14. Some quantitative indices of the oribatid mite community during the day-night cycle
Day and night cycle
Index
6:00 | 12:00 | 18:00 | 24h00 | |
S | 14 | 25 | 25 | 20 |
Average population (individuals/m 2 ) | 4560 | 24160 | 17240 | 6760 |
d | 2.1 ± 0.42 | 2.76 ± 0.91 | 3.02 ± 0.29 | 2.6 ± 1.04 |
J' | 0.78 ± 0.11 | 0.65 ± 0.19 | 0.75 ± 0.19 | 0.80 ± 0.21 |
H' | 1.59 ± 0.10 | 1.75 ± 0.56 | 2.00 ± 0.33 | 1.63 ± 0.67 |
1-Lambda' | 0.74 ± 0.08 | 0.72 ± 0.16 | 0.80 ± 0.12 | 0.78 ± 0.16 |
