3.3.2. Current status of patients using antihypertensive drugs after intervention Table 3.17: Percentage of patients using antihypertensive drugs after intervention

Practice

Target group		Total
Proof	Intervention	Total
Use medicine	Quantity	70	117	187
Use medicine	Proportion	46.4%	77.5%	61.9%
p < 0.05
Be reminded take medicines	Quantity	8	74	82
Be reminded take medicines	Proportion	5.3%	49.3%	27.2%
p < 0.05
Total		151 (100%)	151 (100%)	302 (100%)

Maybe you are interested!

After the intervention, regarding the use of antihypertensive drugs, 61.9% of the patients in the study sample were using them, of which 46.4% were in the control group and 77.5% in the intervention group. The rate of drug use in the intervention group was statistically higher than that in the control group.

Regarding medication reminders after the intervention, although the group reminder solution was no longer supported before the 2-month evaluation period, in the intervention group, up to 49.3% of patients were still reminded to take medication in the past week while in the control group only 5.3% of patients were reminded. The rate in the intervention group was statistically higher than that in the control group.

3.3.3. Status of treatment compliance after intervention

Table 3.18: Morisky score distribution of patients after intervention (n = 182)

Morisky Point

Proof	Intervention	Shared
0	0	25	25
1	22	51	73
2	4	10	14
3	9	15	24
4	9	4	13

8	1	9
6	7	5	12
7	10	1	11
8	1	0	1
Total	70	112	182

Table 3.20: Distribution of compliance status according to Morisky scale after CT

Compliance level

treatment

Control group		Intervention group		Shared
n	%	n	%	n	%
Good	0	0	25	16.6	25	8.3
Medium	26	17.2	61	40.4	87	28.8
Non-compliance	125	82.8	65	43.0	190	62.9
Total	151	100.0	151	100.0	302	100.0
χ 2 = 58.0 p < 0.05

According to the Morisky scale, after the intervention, in the control group, no patient achieved good treatment compliance; 26 patients had average compliance (17.2%) and up to 82.8% of patients did not comply with treatment. Meanwhile, in the intervention group, up to 16.6% of patients had good treatment compliance and 40.4% of patients had average compliance. The difference after the intervention between the control group and the intervention group was statistically significant.

If we calculate according to 2 levels including compliance (good and average) and non-compliance (remaining) according to the concept used in the study, we have:

Table 3.21: Patient compliance rate after intervention

Treatment adherence rate

Target group		Total
Proof	Intervention	Total
Quantity	26	86	112
Proportion	17.2%	57.0%	37.1%
Total	151 (100%)	151 (100%)	302 (100%)
p < 0.05

On average, in the study sample, after intervention, 37.1% of patients adhered to treatment and 62.9% did not adhere to treatment. Of which, the adherence rate in the control group was 17.2%, lower than that in the intervention group at 57.0%. The difference between the control group and the intervention group was statistically significant.

To explain this when analyzing the qualitative results, in-depth interviews showed that when patients are reminded to take their medication, they will be aware that taking their medication is very important. Receiving reminders and encouragement from those around them also makes patients more committed to the treatment process. Patients also believe that the Interpretation Board is a good support for patients, helping them understand the meaning of the measured values as well as marking them:

PVS Patient Nam, 76 years old, Dong Co commune:

“… When I first came back from the hospital, my wife and I reminded me to take my medicine. After a while, I got used to it and when my son went to work far away, no one reminded me. I told them that my friends who were in the same situation as me often came over to encourage me…and if they reminded me to take my medicine, I wouldn’t forget and I would see that this treatment was important…so I had to continue taking it. I knew that the disease was still there …”

PVS BS Tien Hai District Medical Center:

“… There is this thing that patients write down, I can see it just by looking at it. If they bring it to me and I find the medicine is not suitable, I can easily change it. But old patients always remember and forget, they say it is high, but when asked how much it is, how can I say it? Sometimes, when I ask about any medicine, they say it feels comfortable, so I just prescribe it, …‖

Group discussions with health station staff showed that the station really liked the use of the Interpretation Board for patients to record and monitor blood pressure indexes over time and wanted a program to support patients to use this board widely at home:

TLN Tay Giang commune :

“… It's not that the elders don't know, but if you bring this table, one elder will tell another, and people will understand everything, and one person will tell another, and people who have never measured before may also want to measure to compare…‖

3.4. Evaluation of intervention results

3.4.1. Changes in knowledge and skills in blood pressure measurement before and after intervention

95%

68%

71%

59%

61%

54%

38%

36%

Control Group - Knowledge

Intervention Group - Knowledge

Control group -

Skill

Intervention Group - Skills

100%

90%

80%

70%

60%

50%

40%

30%

20%

Before CT After CT

Figure 3.1: Changes in knowledge and skills in self-monitoring BP after CT

After the intervention, the proportion of patients with correct knowledge about BP monitoring in the intervention group increased from 68.2% to 94.6% and the proportion with correct blood pressure measurement skills increased from 53.6% to 71.2% while these two proportions also increased slightly in the control group.

Analyzing the change from no knowledge to knowledge about self-monitoring blood pressure before and after the intervention, we have the distribution according to the following table:

Table 3.22: Distribution of patients with knowledge status change on self-monitoring of blood pressure Before and After CT

After intervention
Have knowledge	No knowledge	Shared
Before intervention	Proof	Have knowledge	89	0	89
	Proof	No knowledge	3 (4.8%)	59	62 (100%)
	p > 0.05 (Mc-Nemar test)
	Intervention	Have knowledge	103	0	103
	Intervention	No knowledge	38 (82.6%)	8	46 (100%)
	p < 0.05 (Mc-Nemar test)
	Shared	Have knowledge	192	0	192
	Shared	No knowledge	41 (38%)	67	108 (100%)
	p < 0.05 (Mc-Nemar test)

After the intervention, in the control group, 3 patients, equivalent to 4.8% of the group without knowledge before the intervention, changed their status from having no knowledge about self-monitoring of blood pressure to having knowledge about self-monitoring of blood pressure. However, the change from having no knowledge to having knowledge in the control group was not statistically significant. Meanwhile, in the intervention group, after the intervention period, 38 patients, equivalent to 82.6% of patients who had no correct knowledge about self-monitoring of blood pressure, changed to having correct knowledge. And the change in the intervention group was statistically significant. Thus, it can be seen that the intervention really brought about an improvement in the patients' knowledge about self-monitoring of blood pressure.

On the other hand, when analyzing the change in patients' correct blood pressure measurement skills before and after the intervention in both groups, we have:

Table 3.23: Distribution of patients who changed status from not knowing how to measure BP to knowing how to measure BP correctly

After intervention
Already know how to measure	Unknown	Shared
Before intervention	Proof	Already know how to measure	46	7	53
	Proof	Unknown	11 (11.5%)	85	96 (100%)
	p > 0.05 (Mc-Nemar test)
	Can card	Already know how to measure	59	18	77
	Can card	Unknown	45 (65.2%)	24	69 (100%)
	p < 0.05 (Mc-Nemar test)
	Shared	Already know how to measure	105	25	130
	Shared	Unknown	56 (33.9%)	109	165 (100%)
	p < 0.05 (Mc-Nemar test)

After the intervention, in the control group, 11 patients, accounting for 11.5%, changed from not knowing how to measure blood pressure themselves to having the skills to measure blood pressure themselves. However, the change in the control group was not statistically significant. In the intervention group, after the intervention period, 45 patients, equivalent to 65.2% of the patients who did not know how to measure blood pressure before the intervention, knew how to measure blood pressure correctly after the intervention. And the change in the intervention group was statistically significant. Thus, it can be seen that the intervention really helped improve the patients' skills to measure blood pressure correctly.

3.4.2. Changes in blood pressure measurement practices before and after intervention

87.9%

87.4%

62.2%

54.9%

51.0%

28.0%

13.9%

24.5%

100%

Control group -

Measure blood pressure

Intervention group

- Measure BP

Control group -

Record index

Intervention group

- Record index

90%

80%

70%

60%

50%

40%

30%

20%

10%

Before CT After CT

Figure 3.2: Percentage of patients who self-monitored BP and recorded pre- and post-CT readings

Comparing the results achieved in increasing self-monitoring of blood pressure with the intervention target, we see that after the intervention, this rate increased by 37.4% in the group of patients receiving the intervention while in the control group, this rate only increased slightly at 7.3%. Thus, the intervention program achieved higher than the set target of increasing the rate of regular self-monitoring of blood pressure.

Analyzing the changes of the 2 groups before and after the intervention in improving the practice of self-monitoring BP at home and recording the index, we have the following tables:

Table 3.24: Distribution of patients who changed from not measuring blood pressure at home to self-monitoring blood pressure at home before and after intervention

After intervention
Practice measuring	No practice measurement	Shared
Before intervention	Proof	Practice measure	76	7	83
	Proof	No practice measurement	18 (26.5%)	15	68 (100%)
	p < 0.05 (Mc-Nemar test)
	Intervention	Practice measure	68	9	77
	Intervention	No practice measurement	64 (86.5%)	10	74 (100%)
	p < 0.05 (Mc-Nemar test)
	Shared	Practice measure	144	16	160
	Shared	No practice measurement	82 (57.7%)	60	142 (100%)
	p < 0.05 (Mc-Nemar test)

After the intervention, in the control group, 18 patients (26.5%) changed their status from not practicing blood pressure monitoring to practicing blood pressure monitoring. The change in the control group was statistically significant. In the intervention group, after the intervention period, 64 patients, equivalent to 86.5% of the patients who had not practiced before the intervention, changed to the status of practicing blood pressure monitoring after the intervention. And the change in the intervention group was statistically significant. The above results show that after the intervention, patients had significant improvements in increasing their practice of self-monitoring blood pressure. However, it is not really certain whether it was due to the intervention alone or a change over time and other errors because the study was short-term, patients were interviewed many times, leading to spontaneous changes in
